O SERIES CLASS I DIVISION II IECEX & ATEX
Green Ignite's Explosion-Proof O Series, engineered for Class 1, Division 2 hazardous environments, and certified for both IECEx and ATEX standards. Available in two mount options – Ceiling mounted and Wall mounted.
Each option includes essential features such as a wire guard, globe, and heat sink for optimal functionality. You have the flexibility to choose between two power options: 20W delivering 2,800 Lumens or 30W offering 4,200 Lumens, both compatible with a voltage range of 100-277V. Additionally, these fixtures are dimmable, providing versatility in lighting control to suit specific needs.
Green Ignite's Explosion-Proof O Series, engineered for Class 1, Division 2 hazardous environments, and certified for both IECEx and ATEX standards. Available in two mount options – Ceiling mounted and Wall mounted.
Each option includes essential features such as a wire guard, globe, and heat sink for optimal functionality. You have the flexibility to choose between two power options: 20W delivering 2,800 Lumens or 30W offering 4,200 Lumens, both compatible with a voltage range of 100-277V. Additionally, these fixtures are dimmable, providing versatility in lighting control to suit specific needs.
Green Ignite's Explosion-Proof O Series, engineered for Class 1, Division 2 hazardous environments, and certified for both IECEx and ATEX standards. Available in two mount options – Ceiling mounted and Wall mounted.
Each option includes essential features such as a wire guard, globe, and heat sink for optimal functionality. You have the flexibility to choose between two power options: 20W delivering 2,800 Lumens or 30W offering 4,200 Lumens, both compatible with a voltage range of 100-277V. Additionally, these fixtures are dimmable, providing versatility in lighting control to suit specific needs.
PART NUMBERS
GI-EPO-C100-C1D2 | 20W | 2,800LM | 100-277V | 5000K | CEILING MOUNTED
GI-EPO-C100-C1D2WM | 20W | 2,800LM | 100-277V | 5000K | WALL MOUNTED
GI-EPO-C150-C1D2 | 30W | 4,200LM | 100-277V | 5000K | CEILING MOUNTED
GI-EPO-C150-C1D2WM | 30W | 4,200LM | 100-277V | 5000K | WALL MOUNTED
CLASSIFICATIONS
ATEX Marking
II 2G Ex eb mb IIC T6/T5/T4 Gb
|I 2D Ex tb IIIC T80°C/T95°C/T130°C Db
IP6б
IECEx Marking
Ex Eb mb lIC T6/T5/T4 Gb
Ex tb IIIC T80°C/T95°C/T130°C Db IP66
UL844 Marking (North American)
Class I, Division 2, Groups A, B, C, D
Class Il, Division 1, Groups E, F, G
Class II, Division 2, Groups F, G
Class III
Marine Marking
UL 1598A
Other Rating
NEMA 3, 4X, IP66, IK08
-
Rated for high temperatures, humidity, dust & vapor locations
Heavy duty & high impact resistant
0-10V Dimmable
Tempered glass for high heat resistance
Warranty: 6 Years
Efficacy: 140lm/W
Beam Angle: 120 Degrees
Gross Weight: 11.90lbs
Ambient temperature (F): -40 - 140 Degrees
CRI: 80
Dimensions: 5.71” x 10.04”
10KvA Surge protection
-
GI-ACC-EPCM
Ceiling mount (for ceiling mounted models)GI-ACC-EPWM
Wall mount (for wall mounted models)GI-ACC-EPPG
Protective guardGI-ACC-EPG
GlobeGI-ACC-EPHS
Heat sink -
GI-ACC-EPPM
Pendant mountGI-ACC-EPWE
Wall elbowGI-ACC-EPSMA
Surface mounting armGI-ACC-EP25S
25 Degree pole supportGI-ACC-EP90WJB
90 Degree wall support & Junction boxGI-ACC-EP25WS
25 Degree wall supportGI-ACC-EP90S
90 Degree pole supportGI-ACC-EPH
Hook mount -
GI-ACC-EPR
ReflectorGI-ACC-EPEX
ExtensionGI-ACC-EPSSP
Straight swing pipeGI-ACC-EPPB
Bended pipeGI-ACC-EPJB
Junction boxGI-ACC-EPPS
Photocell sensorGI-ACC-EPC
Pendant chainGI-ACC-EPEDK15
15W Emergency battery back-up kitGI-ACC-EPED15C
Conduit for 15W Emergency battery back-up kit -
-
Housing: Copper free aluminum
Lens: Tempered glass
